Response Spectra

Station: San Bernardino - 5-story CSUSB Library
Station Owner: California Strong Motion Instrumentation Program
Station Latitude & Longitude: 34.1830, -117.3230

Earthquake: Northridge
Hypocentral Distance: 113.6 km

Processing Info: CSMIP

(Use the back button on your browser to return to the previous page)
 Reconfigure Plots:
% Damping
Accleration Units
Max Period (sec)
Scale Factor for Data
Overlay response spectrum:
  None
  UBC 1997 Help
  Ca
  Cv
  IBC 2000   or    Ground-motion Help
  SDS
  SD1
  Generic design spectrum Help
  Max
  Ca
  T1
  T2
  T3
 Component: 90 Roof, N. Wall  PGA: -110.70 cm/s/s






accelerogram bandpass filtered with ramps at .300- .600 and 23.00-25.00 cyc/sec


 Component: 90 Roof, S. Wall  PGA: 205.40 cm/s/s






accelerogram bandpass filtered with ramps at .300- .600 and 23.00-25.00 cyc/sec


 Component: 90 Roof, Ctr  PGA: 122.90 cm/s/s






accelerogram bandpass filtered with ramps at .300- .600 and 23.00-25.00 cyc/sec


 Component: 180 Roof, Ctr  PGA: 88.50 cm/s/s






accelerogram bandpass filtered with ramps at .300- .600 and 23.00-25.00 cyc/sec


 Component: 90 3rd Flr, S. Wall  PGA: 79.10 cm/s/s






accelerogram bandpass filtered with ramps at .300- .600 and 23.00-25.00 cyc/sec


 Component: 90 3rd Flr, Ctr  PGA: -59.70 cm/s/s






accelerogram bandpass filtered with ramps at .300- .600 and 23.00-25.00 cyc/sec


 Component: 180 3rd Flr, Ctr  PGA: 48.40 cm/s/s






accelerogram bandpass filtered with ramps at .300- .600 and 23.00-25.00 cyc/sec


 Component: Up Basement  PGA: -18.40 cm/s/s






accelerogram bandpass filtered with ramps at .300- .600 and 23.00-25.00 cyc/sec


 Component: 90 Basement  PGA: 33.90 cm/s/s






accelerogram bandpass filtered with ramps at .300- .600 and 23.00-25.00 cyc/sec


 Component: 180 Basement  PGA: -33.60 cm/s/s






accelerogram bandpass filtered with ramps at .300- .600 and 23.00-25.00 cyc/sec
