Response Spectra

Station: Redlands, CA - 1-Story Warehouse
Station Owner: California Strong Motion Instrumentation Program
Station Latitude & Longitude: 34.0660, -117.2140

Earthquake: Northridge
Hypocentral Distance: 124.5 km

Processing Info: CSMIP

(Use the back button on your browser to return to the previous page)
 Reconfigure Plots:
% Damping
Accleration Units
Max Period (sec)
Scale Factor for Data
Overlay response spectrum:
  None
  UBC 1997 Help
  Ca
  Cv
  IBC 2000   or    Ground-motion Help
  SDS
  SD1
  Generic design spectrum Help
  Max
  Ca
  T1
  T2
  T3
 Component: 90 Roof, 1/4 length point of West Wall  PGA: 184.30 cm/s/s






accelerogram bandpass filtered with ramps at .150- .300 and 23.00-25.00 cyc/sec


 Component: 90 Roof, Ctr  PGA: 149.30 cm/s/s






accelerogram bandpass filtered with ramps at .150- .300 and 23.00-25.00 cyc/sec


 Component: 360 Roof, Ctr of E. Wall  PGA: 69.60 cm/s/s






accelerogram bandpass filtered with ramps at .150- .300 and 23.00-25.00 cyc/sec


 Component: 90 Roof, Ctr of N. Wall  PGA: 41.50 cm/s/s






accelerogram bandpass filtered with ramps at .150- .300 and 23.00-25.00 cyc/sec


 Component: 360 Roof, Ctr of South Wall  PGA: 172.00 cm/s/s






accelerogram bandpass filtered with ramps at .150- .300 and 23.00-25.00 cyc/sec


 Component: 90 Roof, Ctr of South Wall  PGA: -42.80 cm/s/s






accelerogram bandpass filtered with ramps at .150- .300 and 23.00-25.00 cyc/sec


 Component: 90 Roof Ctr of West Wall  PGA: 154.50 cm/s/s






accelerogram bandpass filtered with ramps at .150- .300 and 23.00-25.00 cyc/sec


 Component: 360 Roof Ctr of West Wall  PGA: 68.00 cm/s/s






accelerogram bandpass filtered with ramps at .150- .300 and 23.00-25.00 cyc/sec


 Component: 90 Mid Height on West Wall  PGA: 102.20 cm/s/s






accelerogram bandpass filtered with ramps at .150- .300 and 23.00-25.00 cyc/sec


 Component: 90 Ground Floor  PGA: 43.80 cm/s/s






accelerogram bandpass filtered with ramps at .150- .300 and 23.00-25.00 cyc/sec


 Component: 360 Ground Floor  PGA: 68.00 cm/s/s






accelerogram bandpass filtered with ramps at .150- .300 and 23.00-25.00 cyc/sec


 Component: Up Ground Floor  PGA: -16.10 cm/s/s






accelerogram bandpass filtered with ramps at .150- .300 and 23.00-25.00 cyc/sec
